"Launch Ball" Iluminated LED Pinball Button

This illuminated Pinball Button with the image "Launch Ball" with translucent red LEDs is used to shoot the ball of our Pinball table at the beginning of a game. In case we want to know how to play the Pinball table we have selected we will only have to press this button. This button comes in handy if we decide to replace a mechanical Pinball Shooter / Plunger since, especially in Virtual Pinballs, mounting a mechanical Pinball shooter and making it work with digital hardware and software requires some knowledge This button is designed to be used in mechanical Pinball tables or in a Virtual Pinball.

The "Launch Ball" Iluminated LED Translucent Red Pinball Button includes the microswitch and the LED that allows you to connect up to 12V, although we recommend that you power it with 5V. The inside red bright LEDs will illuminate the credit text giving a decorative, elegant, and also practical touch to your Arcade project.

With a 44mm diameter, this pushbutton can be installed on both metal and wooden panels quickly and easily thanks to the Nut Thread Washer system. This push button can be installed in holes ranging from 44mm to 48mm in diameter.

The LED is compatible with both 5V and 12V. In case the LED stops working, you can easily replace it. At our store you can find loose LED lamps that will serve as replacements.

In order to light up this Pinball button, you will need a 5V or 12V power supply. We recommend that you either directly get it from the Arcade Machine power supply or from one of the 5V pins on the Xin Mo encoder, or the specific Zero Delay LED encoders to light up the LEDs. These Zero Delays are available for 1 or 2 players which are also available at our store.

Mounting Information

To install the LED Arcade push button, you'll need 4.8mm wiring as that is the width of the button action terminals and 6.3mm LED wiring as that is the width of the LED fastons. If you purchase one our interfaces, be sure to select the one with 6.8mm wide terminals wire. You can also purchase extra 6.3mm cables for the Zero Delay LED or the Xin Mo from the links below: Zero Delay / Xin Mo.

Features

• Microswitch and LEDs included
• Elegant and practical
• Blee brand 4.8mm Microswitch
• For 44-48mm diameter holes
• Metal / wood panels
• 12V / 5V voltage
• Easy installation
