Zippy Ultra Light Touch 4.8mm button microswitch VM-05B

The amazing VM-05B Ultra Light Touch Zippy microswitch at an unbeatable price. These microswitches can be installed in any arcade happ type buttons or in classic ILs Eurojoystick 2. With an operating force of only 20gr, the user will be amazed once he tests these super light switches.

Zippy Microswitches have nothing to envy from the famous and classic Cherry microswitches. In fact, Zippy is the brand that has been supplying microswitches to Suzo HAPP joysticks and push buttons since they stopped using Cherry parts.

You are looking at a super light touch microswitch. Just so that you can have an idea, the Cherry Micros D44X have an operating force of 75gr while the Zippy micros have an actuation force of only 20gr. They also have a service life of 10,000 and support a voltage of 50-60Hz.

Zippy's VM-05B Arcade Pushbutton Microswitches come with 4.8mm wide terminals so when purchasing, please notice this to see whether they match the existing Jamma wiring in your Arcade Cabinet, USB encoder or any other devices.

Features

• 4 x Zippy Microswitches
• 4.8mm terminals
• Nominal charge 5A 125/250VAC
• Contact resistance 30m Ω (Max.)
• Insulation resistance ≥100mΩ
• Operating force 20gr
• Mechanical life ≥ 10,000 cycles
• Operating temperature -25 ~ +85 ?
• Supports 50-60Hz) voltage... AC 1,000V RMS
