Zippy Heavy Touch 4.8mm button microswitch VM-05F

The amazing VM-05F Heavy-touch Zippy microswitch at an unbeatable price. These microswitches can be installed in any arcade happ style buttons or in classic ILs Eurojoystick 2. With an operating force of 125gr, the user will find that these switches are quite heavy touch.

Zippy Microswitches have nothing to envy from the famous and classic Cherry microswitches. In fact, Zippy is the brand that has been supplying microswitches to Suzo HAPP joysticks and push buttons since they stopped using Cherry parts.

This is a quite heavy-touch microswitch ideal for mounting on player 1 and 2 buttons, as they may be a little hard to use on action buttons. Of very good quality, these microswitches have a lifespan of 10,000 and withstand a voltage of 50-60Hz.

Zippy's VM-05F Arcade Pushbutton Microswitches come with 4.8mm wide terminals so when purchasing, please notice this to see whether they match the existing Jamma wiring in your Arcade Cabinet, USB encoder or any other devices.

Features

• 4 x Zippy Microswitches
• 4.8mm terminals
• Nominal charge 5A 125/250VAC
• Contact resistance 30m Ω (Max.)
• Insulation resistance ≥100mΩ
• Operating force 125gr
• Mechanical life ≥ 10,000 cycles
• Operating temperature -25 ~ +85 ?
• Supports 50-60Hz) voltage... AC 1,000V RMS
